Simes S.4055.14 Blitz 2f 90 +4 +qt32 105w e27 gray

S.4055

BLITZ 2 180° WINDOW

-TYPE

Wall-mounted device.

Degree of protection IP 65

-FEATURES OF THE MATERIALS

Body in die-cast primary aluminium EN AB-47100 with high

resistance to oxidation.

Tumbling process to prepare for the painting phase.

Screws in A4 stainless steel with a high molybdenum content of 2.5-3%.

Silicone ricotta gaskets.

Extra-resistant double painting carried out in 3 phases:

1) BONDERITE treatment with chemical protection of the material

metal-free fluozirconium containing ceramic nanoparticles that

create a cohesive, inorganic, high-density layer.

2) PRE-POLYMERIZATION cycle with application of the primer

epoxy with characteristics of overpaintable on the appliance and of

high resistance to oxidation thanks to the presence of zinc.

3) POLYMERIZATION cycle with the application of polyester powder

with high resistance to UV rays and atmospheric agents,

with salt spray test resistance of 1500h.

Mechanical resistance of glass IK 10

-LIGHTING PERFORMANCE

The lenses are tempered glass with a curved shape obtained through a particular

moldings, they are installed using special "slides".

Yield 6%

-INSTALLATION AND MAINTENANCE

The very robust shell, made of die-cast aluminium, is

secured to the base by four AISI 316L stainless steel screws.

The lamp holders are positioned on a steel base whose

the planar position can be adjusted.

-WIRING

Double power cable entry with PG13.5 cable glands (Ø 6÷12 mm).

Insulation class: CLASS I

Available colors: ALUMINUM GREY (code 14)

Weight: 3.63 kg

Glow wire test: 850°C

Appliances supplied complete with lamp.

Use only SYLVANIA DLX-T lamp
