Orieme OC 200 CS Centrifugal Ceiling Extractor 170 m3/h

Orieme OC 200 CS Centrifugal Extractor for False Ceilings: Optimal Performance for Small Spaces

The Orieme OC 200 CS Centrifugal Ceiling Extractor is the ideal solution for ensuring proper ventilation in small spaces, such as bathrooms, kitchens, or utility rooms. Here's a detailed description of this efficient device:

High Extraction Capacity: With a flow rate of 170 cubic meters per hour (m³/h), the Orieme OC 200 CS Centrifugal Extractor ensures rapid and effective extraction of stale and humid air, guaranteeing a fresh and healthy environment.

Compact and Slim Design: The compact and slim design of the OC 200 CS makes it perfect for installation in false ceilings, ensuring effective ventilation without compromising the aesthetic appearance of the room.

High-Quality Materials: Made of high-quality materials, this centrifugal vacuum cleaner is designed to last over time and ensure reliable long-term performance.

Low Noise Emission: Thanks to its construction and silent motor, the OC 200 CS offers discreet operation, ensuring maximum acoustic comfort in the environments in which it is installed.

Easy Installation and Maintenance: Equipped with clear and intuitive instructions, the centrifugal vacuum cleaner is easy to install and requires minimal maintenance, ensuring simple and hassle-free management.

Suitable for Various Environments: Ideal for bathrooms, kitchens, laundry rooms and other small domestic or commercial environments, the OC 200 CS is the perfect choice for ensuring optimal ventilation in limited spaces.

Trusted Brand: Orieme is a renowned brand in the ventilation industry, known for the quality and reliability of its products. With the OC 200 CS, Orieme offers an efficient and affordable solution for ensuring a comfortable and healthy environment.

In conclusion, the Orieme OC 200 CS Centrifugal Extractor Fan for False Ceilings is the ideal choice for those seeking optimal performance in small spaces. With its effectiveness, reliability, and ease of installation, this centrifugal extractor offers an excellent solution for improving indoor air quality simply and efficiently.

Mountable on false ceilings with a maximum distance of 40 cm from the ceiling

load-bearing, with fixing system supplied

For false ceilings greater than 40 cm up to a maximum of 1 metre,

use the OCS T kit (optional)

Maximum thickness of false ceilings 4 cm

Tube diameter 100 mm

Flow rate m3/h 170

Supply voltage at 50 Hz 230 V

Pressure at nominal flow rate mm H2O 2.75

MAX pressure (at zero flow) mm H2O 6.80

Power consumption (W) 26

Sound pressure level at 3 m dB (A) 39

Declaration of conformity

Approvals

Insulation class I

Common degree of protection

Max. operating temperature 40°C

Weight 1.8

Dimensions (LxHxD cm) 29.4x29.4x22.5
