Theben 4900251 Rmg 8 knx actuator 8can
Theben S.r.l.
250.10 €
Tax included
Last items in stock
_1732199632.png){kind=icon}
Order by
and your product will be shipped
In Stock: 1/PZ
RMG 8 S KNX Theben 8-channel switch actuator
Condizione prodotto:New
Secure Payments
Delivery times
Fedex Road Europe: 5-7 working days
Dhl Road Europe: 3-5 working days
DHL Express International: 2-3 working days
Legal guarantee of conformity
Payments Method
- MIX2 8-Channel Switch Actuator
- MIX2 Basic Module
- Possibility of expansion up to 24 channels
- Up to 2 MIX or MIX2 expansion modules can be connected to a basic module
- Device and KNX bus module can be replaced independently
- Removable KNX bus module that allows the replacement of devices without reprogramming
- Manual commissioning and use of the switching actuators is also possible without a KNX bus module
- Switching status indication with LED for each channel
- Manual control on the device (even without bus voltage)
- Adjustable properties: e.g. switching, delayed switching, pulse function
- Connections, contact type (open/close) and participation in central commands such as permanent ON, permanent OFF, centralized arming and scene storage/recall
- Switching functions: e.g. ON/OFF, pulse, ON/OFF delay, stair lights with pre-warning
- Logical connections: e.g., locking, AND, unlocking, OR
| Valid values from serial number | 1318XXXXX |
| KNX operating voltage | Bus voltage, ≤4 mA |
| Operating voltage | 110 – 240 V AC 50 – 60 Hz |
| Frequency | 50 – 60 Hz |
| Self-consumption | ~0.3 W |
| Max. dissipation power | 6.4 W |
| Mounting type | DIN rail mounting |
| Length | 4 modules |
| Connection type | KNX bus terminal |
| Maximum cable cross-section | Solid: 0.5 mm² (Ø 0.8) to 6 mm² | Wire with sleeve: 0.5 mm² to 4 mm² |
| Number of channels | 8 |
| Contact Type | Closure, 16 A, 3 A |
| Opening width | |
| Max switching power | 3680 W |
| Max load for incandescent/halogen lamps | 2000 W |
| Parallel compensated fluorescent lamp load (conventional ballast) | 1300 W (140 µF) |
| Uncompensated fluorescent lamp load (conventional ballast) | 2000 VA |
| Fluorescent lamp load (electronic ballast) | 1200 W |
| Energy-saving lamps | 300 W |
| LED lamp | 55 W |
| LED lamp 2-8 W | 600 W |
| LED lamp > 8 W | 600 W |
| Inrush current | max. 800 A / 200 µs |
| Output voltage | 240 V AC |
| Switching output | Zero potential |
| Switching of different phases | Possible |
| Suitable for SELV | Yes, if all SELV channels are activated |
| Load C | |
| Model | Basic module |
| Operating ambient temperature | -5°C … 45°C |
| Type of protection | IP 20 |
| Insulation class | II |
