Theben 4900251 Rmg 8 knx 8can actuator
THEBEN
250.10 €
Tax included
Last items in stock
_1732199632.png){kind=icon}
Order by
and your product will be shipped
In Stock: 1/PZ
RMG 8 S KNX Theben 8-channel switching actuator
Condizione prodotto:New
Secure Payments
Delivery times
Fedex Road Europe: 5-7 working days
Dhl Road Europe: 3-5 working days
DHL Express International: 2-3 working days
Legal guarantee of conformity
Payments Method
- MIX2 8-channel switching actuator
- MIX2 basic module
- Possibility of expansion up to 24 channels
- Up to 2 MIX or MIX2 expansion modules can be connected to a basic module
- Luminaire and KNX bus module can be replaced independently
- Removable KNX bus module that allows the replacement of devices without reprogramming
- Manual commissioning and use of the switching actuators are also possible without a KNX bus module
- Switching status indication with LED for each channel
- Manual control on the device (even without bus voltage)
- Adjustable properties: e.g. switching, delayed switching, pulse function
- Connections, type of contact (opening/closing) and participation in central commands such as permanent ON, permanent OFF, centralized arming and scene storage/recall
- Switching functions: e.g. ON/OFF, pulse, ON/OFF delay, staircase lights with warning
- Logical links: e.g. locking, AND, unlocking, OR
| Valid values from serial number | 1318XXXXX |
| KNX operating voltage | Bus voltage, ≤4 mA |
| Operating voltage | 110 – 240 V AC 50 – 60 Hz |
| Frequency | 50 – 60 Hz |
| Self-consumption | ~0.3W |
| Max. dissipation power | 6.4W |
| Mounting type | DIN rail mounting |
| Length | 4 modules |
| Connection type | KNX bus terminal |
| Maximum cable section | Solid: from 0.5 mm² (Ø 0.8) to 6 mm² | Cable with sleeve: from 0.5 mm² to 4 mm² |
| Number of channels | 8 |
| Contact type | Closing, 16 A, 3 A |
| Opening width | |
| Max. switching power | 3680W |
| Max load incand./halogen lamps | 2000W |
| Loading fluorescent lamps (conventional ballast) compensated in parallel | 1300W (140µF) |
| Loading of non-compensated fluorescent lamps (conventional ballast). | 2000 VA |
| Loading fluorescent lamps (electronic ballast) | 1200W |
| Energy saving lamps | 300W |
| Led lamp | 55W |
| 2-8 W LED lamp | 600W |
| LED lamp > 8 W | 600W |
| Inrush current | max. 800 A / 200 µs |
| Output voltage | 240V AC |
| Switching output | Potential-free |
| Switching of different phases | Possible |
| Suitable for SELV | Yes, if all SELV channels activate |
| Load C | |
| Model | Basic module |
| Operating ambient temperature | -5°C … 45°C |
| Type of protection | IP 20 |
| Insulation class | II |
