Minibrique S.4531.14 round recessed light with casing 1x10w/20w g4 grey ip54

The Minibrique S.4531.14 is a recessed lighting fixture with a recessed housing, designed for outdoor installation. Some of its basic features include:

• Model : Minibrique S.4531.14
• Type of fixture : Recessed wall or floor
• Compatible lamp : 10W or 20W G4 bulb (purchased separately)
• Color : Grey
• Degree of protection : IP54 (protection against dust and splashes of water)
• Application : Used for outdoor lighting of gardens, paths, terraces, etc.
• Design : The recessed design with formwork offers a clean and unobtrusive look, integrating well with the surrounding environment.
• Materials : Made from weather-resistant materials to ensure durability and resistance over time.
• Installation : It must be installed in a recessed box in the ground or on the wall, providing uniform and discreet lighting.

This versatile fixture is suitable for outdoor lighting, ideal for creating evocative atmospheres and improving the safety of outdoor pathways. Before installing, it's important to check compatibility with your desired G4 bulb and ensure you comply with all local safety and installation regulations.

S.4531 MINIBRIQUE ROUND - TYPE Wall-mounted luminaire. IP 54 protection rating - MATERIAL CHARACTERISTICS Body in extruded EN AW-6060 and die-cast EN AB-47100 primary aluminium with high resistance to oxidation. Tumbling process for preparation for the painting phase. Screws in A4 stainless steel with a high 2.5-3% molybdenum content. Annealed silicone gaskets. Extra-resistant painting carried out in 3 phases: 1) BONDERITE treatment with a chemical protection of metal-free fluorozirconic material containing ceramic nanoparticles that create a cohesive, inorganic, high-density layer. 2) PRE-POLYMERIZATION cycle with application of the epoxy primer with characteristics that make the luminaire easy to paint over and highly resistant to oxidation thanks to the presence of zinc. 3) POLYMERIZATION cycle with the application of bonded polyester powder with high resistance to UV rays and atmospheric agents, with resistance to the salt spray test for 1500h. Mechanical resistance of the glass IK 06 - LIGHTING PERFORMANCE Optical reflector in 99.98% pure aluminum, turned, anodized and polished. Diffuser in opalized and dotted tempered glass. Light source, with fixed lamp position. Efficiency 15% - INSTALLATION AND MAINTENANCE Installation is easy thanks to the predisposition of the polypropylene formwork. Suitable plastic supports reinforce the structure in the middle. This measure prevents deformation during the formation of walls by means of concrete pouring. The luminaires are secured to the formwork with stainless steel screws. The ribbed glass slightly screens the view of the inside of the luminaire. The ring and the grille block the ribbed glass diffuser, covering the edge of the formwork and therefore also the edge of the hole. This hides any imperfections in the masonry. - WIRING Single power cable entry with grommet. Insulation class CLASS III Available colours ALUMINIUM GREY (code 14) Weight 0.38 Kg Glow Wire test 850°C Lamps supplied upon request only.
